We have a range of tools for nearly any of your cutting needs, including
• Flat Sheet and 5-axis Laser Cutting
• CNC Punching
• Shearing
• Sawing

Primary Cutting Equipment

Our cutting equipment is where your project begins! Scroll down to see the equipment that will be used to start your project on its journey through our shop.

BYSTRONIC BYSTAR 6000 FIBER

Bystronic Bystar 6000 Fiber

Specifications:

  • 6000 Watt Fiber Laser
  • Material capacities: Up to 1" Mild Steel, 1.180" Stainless Steel, .590" Brass, and .47" Copper
  • Automatic nozzle changer w/ 64 stations, auto focus, auto nozzle centering, nozzle cleaning and calibration.
  • Detection Eye option allows for faster sheet location prior to cutting vs. using the nozzle to edge detect.
  • ByTrans Extended Automation system. Two Cassettes for material(s). Load/unload sheets, large part removal, scrap skeleton removal. Sixty second cycle time for pallet change. Can run autonomously.

TRUMPF TRUMATIC L3050

Trumpf Trumatic L3050

Specifications:

  • 5000 Watt Co2 Resonator
  • Material capacities: Up to 1" Mild Steel, 3/4" Stainless, 1/2" Aluminum
  • Pallet changer system with 60" x 120" tables and LiftMaster system for sheet load / unload
  • Capable of running in an automated "Lights Out" state for unattended operation.
  • Multiple head/focal lengths: 75", 5", 7.5", 9" to cover a wide thickness range.

TRUMPF TRULASER CELL 7040

TRUMPF TRULASER CELL 7040

Specifications:

  • 3000 Watt TruDisk Fiber 5-Axis Laser
  • Working range:
    • X axis: 4000 mm (157.4798 in.)
    • Y axis: 1500 mm (59.05494 in.)
    • Z axis: 750 mm (29.52747 in.)
  • Dynamic Cutting Optics +/- 10 mm (0.39369 in.)
  • Axis Speed:
    • X/Y/Z Linear Axes: 100 m/min (3937 ipm)
    • Simultaneous Axes: 173 m/min (6811 ipm)
  • Max Repeatability: X/Y/Z Linear Axes: 03 mm (0.001181 in.)  Rotation Axes B/C:  0.005 deg.

PRIMA RAPIDO 5-AXIS

Prima Rapido 5 axis

Specifications:

  • 3500 Watt Co2 Laser
  • Axes Strokes: X 126", Y 60", Z 24", A 360 degrees continuous, B +/- 120 degrees (with respect to Z)
  • 5" and 7.5" Focal Length cutting heads. Optional Split Cabin.
  • Off-line programming and fixture design using Catia FasTrim software.
  • Ideal for deep drawn, spun, or stamped parts.
  • The ability to trim contours and add holes and shapes to existing 3-D parts.

TRUMPF TRUMATIC 500R

Trumpf Trumatic 500R

Specifications:

  • Maximum Punching Force: 25 Tons
  • Maximum Material Thickness: 0.25 inches
  • Maximum Punch Diameter: 3 inches
  • Working Range, without reposition (X -Y): 100" x 50"
  • Simultaneous positioning speed of 4300 ipm
  • C Axis rotation 360° / second. 600 strokes per minute.
  • 18 Tool Stations with 2 worksheet clamps. 5 - 6.5 second tool change.
  • Multi-tool capable. Accuracy +/- 0.002", Repeatability +/- 0.0012"

CINCINNATI 2500 CNC SHEAR

Cincinnati 2500 CNC Shear

Specifications:

  • 1/4" Mild Steel
  • 1/4" Aluminum
  • 10 Ga. Stainless Steel
  • 10' wide, with programmable back-gage up to 48"
  • Pneumatic sheet supports for gaged material

MARVEL TOUCH TECH 60 - Series 2125

MARVEL TOUCH TECH 60 - Series 2125

Specifications:

  • Round Stock: 25" Dia. @ 0 degrees, 17" Dia, @ 45 degrees, 11.25" @ 60 degrees
  • Rectangular (WxH): 20" x 25" @ 0 degrees, 20" x 17" @ 45 degrees, 20" x 11.25" @ 60 degrees
  • Table Load: 8000 lbs., Feed Table Load: 14000 lbs.
  • Maximum Vise Opening: 25"
  • Shuttle Stroke: 48"
  • Blade Size: 25" x 0.050" x 17' 6", Blade Speed: 30-650 FPM
